Amp/Relay Module
Input/Output Identification
Item #5
5-1 Radio In
5-2 Backlight
5-3 Low Current System Switch (+ Activation)
5-4 Horn Ring (+ Activation)
5-5 Park Kill (+ Activation)
5-6 Radio In
5-7 Icon Driver
5-8 Low Current System Switch (- Activation)
5-9 Horn Ring (- Activation)
5-10 Park-Kill (- Activation)
Item #7
7-1 Outlet #1
7-2
7-3
7-4
7-5
7-6
7-7
7-8
Outlet #2
Outlet #3
Outlet #4
Outlet #5
Outlet #6
Outlet #7
Outlet #8
Item #6
6-1 Siren
6-2 Siren
-3 Isolated Relay (Normally Closed)
-4
-5
6
6 Isolated Relay (Normally Open)
6 Isolated Relay (Common)
Item #4
Controller Port
Item #3
USB Port
Item #2
2-1 Dip Switch #1
2-2 Dip Switch #2
2-3 Dip Switch #3
2-4 Dip Switch #4
Item #1
1-1
1-2
1-3
1-4
Relay (+)
Relay (+)
Siren (+)
Ground (-)
1
4321
234
5
678910
1
ON
OFF
234
12
3
4
5
1
2
3 56784
